XP500 Cardboard Finisher for varnish, laminate, and die cut

  • DUAL UV-flexo varnish
  • Optional spot varnish with registration
  • Super gloss varnish
  • Cold foil silver, gold, and special effects.
  • Conveyer for sheet processing
  • Can work as a rotary sheeter
  • Quick job change with magnetic cylinder

Characteristics

The XP500 line is designed to varnish, laminate and die-cut a 500 mm wide web on both sides in one process. It integrates with your digital press and forms a full production line for postcards, brochures and many other products. The end product is placed on a conveyer or packed in boxes at the end of the line.

Designed for postcards, tags, pocket folders and flyers the flexible die cutter offers many possibilities. As standard, the line comes with a sling stacking system but more advanced systems can be added and customised with the exact applications you need:

XP500 runs with double tools for bending lines/folders

All-in-all a very service friendly design that requires a of minimum maintenance.

Watch our tutorials

Technical Specifications

Specifications Metric Imperial
Web width 500 mm 20"
Substrate 80 - 500 µm
Speed Up to 72 m/min Up to 236 ft/min
Die cut repeat range 50 - 558,8 mm 2 - 22"
Max unwind diameter Ø1200 mm (external unw. option)
Output to Conveyor/stacker
Lamination unwind diameter Ø400mm 15.7"
Flexo cliché range Ø228 - 482,6 mm 9 - 19" (Dual side)
Knife box Shear, Crush or Razor
Core diameter 76 mm 3"
UV system GEW Air cooled
Weight 3500 kg 7700 lbs
Dimensions (WxHxD) 7,2 x 1,25 x 1,8 m
Power / Air 3x400VŃ+PE, 32A, 6 bar
Exhaust Ø160 mm, 2x 800 m³/h. Outside.
