UC500 Coater with lamination & flexo varnish

  • Maximum flexibility with UV and water-based varnish
  • Hot-air module for water-based varnish
  • Ideal for banners, folders, and postcards


Experience the power of our Coater with Lamination and Flexo Varnish – a versatile solution designed to seamlessly integrate into both inline and offline digital workflows.

Our cutting-edge converting line offers a comprehensive suite of features, including UV varnish and lamination for achieving super gloss finishes. You have the flexibility to operate this system in line with a dancer or choose the optional offline mode with an unwind module, giving you the freedom to adapt to your specific production needs.

This robust solution caters to a wide range of applications, making it perfect for banners, folders, postcards, and roll-to-roll printed labels (non-die-cut). To ensure ease of operation, we've equipped the system with an intuitive touch display, available for web widths of either 330mm (~13.0 inches) or 515mm (~20.3 inches).

Elevate your printing and converting capabilities with our Coater with Lamination and Flexo Varnish, the ultimate choice for high-quality, efficient digital workflows.


Optional equipment
  • Separate unwind section, max. roll diameter 1000mm (~39.4”)
  • Hot-air module for Aqua varnish
  • Jogger table for sling stacking
  • Spot varnish
  • Corona treater
  • Back scoring / Perforation

Technical Specifications

Specifications Metric Imperial
Web width 100 - 500 mm 4 - 20”
Substrate thickness 20 - 350 µm 0.8 - 13.8 pt
Max. web speed 30 m/ min  98.4 ft
Max. web speed with closed chamber 100 m/ min 328 ft
Unwind/ Rewind
Max. unwind diameter 700 mm 27.6”
Max. rewind diameter 500 mm 19.7”
Max. rewind diameter additional roll 700 mm 27.6”
Core diameter 76,2 or 152,4 mm  3 or 6”
Flexo Station
Print cylinder size 228 - 482,5 mm 9 - 19”
Spot varnish option with digital sensor register control and slow run
Slitting Station
Knife type Pneumatic crush or razor knife
Minimum distance crush 12,7 mm 0.5”
W x D x H 2,0 x 1,4 x 1,7 m 6.6 x 4.6 x 5.6 ft
